現在的超聲波清洗機，對于應用范圍來說是比較廣的，因為這類設備的種類和型號比較多，可以滿足不同領域的應用需求，以及電氣控制柜設置在盒體的一側，和罐過濾液體容納被布置在盒體，并且過濾器的液體存儲設置在罐電解清洗設置在罐中，超聲換能器被布置在電解清洗的罐底。

The current ultrasonic cleaning machine has a wide range of applications, because there are many types and models of this kind of equipment, which can meet the application needs of different fields. The electrical control cabinet is set on one side of the box, and the tank filter liquid storage is arranged in the box, and the liquid storage of the filter is set in the tank, and the electrolytic cleaning is set in the tank, The ultrasonic transducer is arranged at the bottom of the electrolytic cleaning tank.

多個陽極電極銅條和多個陰極電極銅條在其上側橫向排列，陽極電極和陰極電極銅條和陰極電極和彎頭電極銅棒以及陰極電極銅棒縱向設置體具有多個板陰極電極，和用于循環水的泵設置在過濾槽儲存液體，和溢流口被布置在罐電解清洗的一側上，并且被連接到箱液體儲存過濾器通過溢流管，另一側設有循環進水口。

A plurality of anode electrode copper strips and a plurality of cathode electrode copper strips are horizontally arranged on the upper side, the anode electrode and cathode electrode copper strips and cathode electrode and elbow electrode copper rod as well as the longitudinal setting body of cathode electrode copper rod are provided with a plurality of plate cathode electrodes, a pump for circulating water is arranged on the filter tank to store liquid, and an overflow port is arranged on one side of the tank for electrolytic cleaning, And it is connected to the tank, the liquid storage filter passes through the overflow pipe, and the other side is provided with a circulating water inlet.

通過進水管與儲液過濾器水箱內的循環水泵連接，水管內設有過濾器，液體儲存過濾罐入口，液體儲存過濾罐、的底側單獨提供，有一個帶閥門的排水口，目的探討合理使用超聲波清洗機，達到佳清洗效果，該方法被分為兩個機器超聲波清洗，被固定在機器的不同深度位置的超聲能量的瓶的檢測。

The water inlet pipe is connected with the circulating water pump in the water tank of the liquid storage filter. There is a filter in the water pipe. The inlet of the liquid storage filter tank and the bottom side of the liquid storage filter tank are provided separately. There is a water outlet with a valve. The purpose of this paper is to explore the reasonable use of the ultrasonic cleaning machine to achieve the best cleaning effect, The first is the detection of ultrasonic energy bottles fixed at different depth positions of the machine.

通常第二個是超聲能量放置在不同深度的機器上，清洗后用超聲波能量瓶觀察顏色是否變色，探討超聲波頻率對清洗深度的影響，臺機器通常在清洗溶液的下部改變顏色，但是清洗溶液的中間和上部沒有變色，第二臺機器將顏色改變為清洗溶液的任何深度清洗，結論超聲頻率不僅與清洗設備的準確性有關，而且與清洗深度有關，目的探討合理使用超聲波清洗機達到佳清洗效果。

Usually, the second one is that the ultrasonic energy is placed on the machine with different depths. After cleaning, the ultrasonic energy bottle is used to observe whether the color changes, and to explore the influence of ultrasonic frequency on the cleaning depth. The first machine usually changes the color at the lower part of the cleaning solution, but there is no color change at the middle and upper part of the cleaning solution. The second machine changes the color to any deep cleaning of the cleaning solution, Conclusion the ultrasonic frequency is not only related to the accuracy of cleaning equipment, but also related to the cleaning depth. Objective to explore the reasonable use of ultrasonic cleaning machine to achieve the best cleaning effect.
